The ELSS Series  provides emergency lighting for the UL924 required minimum of 90  minutes, or longer based on load Electrical distribution of multiple LED  remotes and normally-on exit signs.  The ELSS includes a distribution section on the main PCB which connects the normally-off remotes with up to 4 separate circuits. Also includes normally-On Exit connections for 5 individual connections.

Upon failure of normal utility power, a solid-state transfer switch automatically activates the remote lamp-heads. Upon resumption of normal utility power, the battery is disconnected from the load and recharged through a microprocessor controlled pulse charger. The battery is a maintenance-free Lithium Iron Phosphate(LiFePO4) type. The ELSS series accepts dual-voltage input of 120 or 277VAC at 50/ 60 Hz. A low voltage battery disconnect (LVD) feature protects the battery from severe damage during prolonged power failures. Manual testing is available at any time using the push-to-test button. Spectron® Self-diagnostics monitors LED status, LED load transfer circuit, battery capacity and charger function and displays any fault detection by means of a flashing code

Self-Test feature automatically runs a 1 minute test once a month and an alternating 30 or 90 minute test once every 6 months.

Multi-color LED indicator provides visible fault detection and charging status.  User initiated 1 or 90-minute system test feature.  15 minute retransfer delay.  Automatic unit transfer in brown-out conditions (below 80% of nominal AC input voltage

The ELSS Series  provides emergency lighting for the UL924 required minimum of 90  minutes, or longer based on load Electrical distribution of multiple LED  remotes and normally-on exit signs.  The ELSS includes a distribution section on the main PCB which connects the normally-off remotes with up to 4 separate circuits. Also includes normally-On Exit connections for 5 individual connections.

Upon failure of normal utility power, a solid-state transfer switch automatically activates the remote lamp-heads. Upon resumption of normal utility power, the battery is disconnected from the load and recharged through a microprocessor controlled pulse charger. The battery is a maintenance-free Lithium Iron Phosphate(LiFePO4) type. The ELSS series accepts dual-voltage input of 120 or 277VAC at 50/ 60 Hz. A low voltage battery disconnect (LVD) feature protects the battery from severe damage during prolonged power failures. Manual testing is available at any time using the push-to-test button. Spectron® Self-diagnostics monitors LED status, LED load transfer circuit, battery capacity and charger function and displays any fault detection by means of a flashing code

Self-Test feature automatically runs a 1 minute test once a month and an alternating 30 or 90 minute test once every 6 months.

Multi-color LED indicator provides visible fault detection and charging status.  User initiated 1 or 90-minute system test feature.  15 minute retransfer delay.  Automatic unit transfer in brown-out conditions (below 80% of nominal AC input voltage
